Newpowa 5 Watt 12V 10BB Mono Solar Panel Tricke Charge RV Marine Boat Off

NewpowaOur goal is to provide you quality solar products, with reasonable price.
This listing is for One:

• Newpowa's New 5W 12V Monocrystalline Solar Panel is ideal for bringing power to small electronics while away from the grid. It is commonly used in RV, marine, gate opener, and many other small off-grid applications.

Specification

Product code

NPA5S-12J

Maximum power (Pmax)

5W

Voltage at Pmax (Vmp)

17.20V

Current at Pmax (Imp)

0.30A

Open-circuit voltage (Voc)

20.23V

Short-circuit current (Isc)

0.32A

Temperature coefficient of Voc

-0.28%/°C

Temperature coefficient of Isc

+0.05%/°C

Temperature coefficient of power

-0.36%/°C

NOCT (Air 20°C; Sun 0.8kW/m² wind 1m/s)

45±2°C

Operating temperature

-40°C to 85°C

Maximum system voltage

1000V DC

Power tolerance

± 3%

Module Dimension  9.06inch×8.46inch×0.71inch / 230mm x 215mm x 18mm
Weight0.62kg / 1.36lbs
MaterialHigh-performance cells encapsulated in EVA (ethylene-vinyl-acetate)
ShippingAll orders in stock will be shipped in 2 business days.Shipping cost is flat to 48 Contiguous States. Other area please contact us for shipping rates. Warranty - Buy with Confidence
 Standard Aluminum Frame Solar Panels:

•  2-year limited materials and workmanship warranty
•  10-year/90% power output warranty
•  25-year/80% power output warranty

Accessories*This auction include one Solar Module only. No cable or controller included, unless stated otherwise.
Please Note:For Large solar system, do not connect solar module/panel with battery directly. A solar controller is a must in between.
Also, if you have any question, feel free to ask.
