10 Pairs Solar Panel Cable Wire Connectors Kit Male & Female Waterproof

10 pairs of MC4 Solar Panel Cable Connectors (10Pcs of MC4 Male and 10Pcs of MC4 Female) Double seal rings for better waterproof effect Quick & simple assembly processing and simple removal of plugs without the aid of any extra instrument Compatible with PV cables with different insulation diameters Resistance of extra high & low temperature and fireproof Load capability with big current and high voltage

10 pairs of MC4 Solar Panel Cable Connectors (10Pcs of MC4 Male and 10Pcs of MC4 Female) Double seal rings for better waterproof effect
Quick & simple assembly processing and simple removal of plugs without the aid of any extra instrument
Compatible with PV cables with different insulation diameters
Resistance of extra high & low temperature and fireproof
Load capability with big current and high voltage

Details:

Protection Class:2
Withstanding Voltage:1000 V DC
Rated Current:22(2.5 mm),30A (4,6 mm)
Contact Resistance:Less than 0.5 Mohms
Insulation Material:PC/PA, black
Temperature Range: -40 C ~ +90 C
Contact Material: Copper, Sliver plated
Flame Class: UL94-VO or UL94-5VA
Rated Current: 30A
Suitable cable: 2.5mm2, 4mm2, 6mm2 (AWG14, AWG12, AWG10)
Pin dimension: 4.0 mm dia.
Contact resistance: ≤0.2mmΩ
Waterproof degree: IP67
Flame class: UL94-VO
Safety Class: Ⅱ
Withdrawal force: ≥50N
Insertion force: ≤50N
Insulation material: PPO + PA
Connecting system: crimping connection
Contact material: copper, tin plated
Temperature range: -40 ℃ ~ +90 ℃
Protection Degree: IP 2X unmated; IP67, mated
Wire Size Range: 2.5mm2, 4mm2, 6mm2[AWG14, AWG12, AWG10]
Insulation Material: PC/PA, black
Contact Material: Copper, Sliver plated
Flame Class: UL94-VO or UL94-5VA
